Product Content
Redundancy as Architecture
Power supplies fail. It is the most common hardware failure mode in deployed appliances. Dual redundant PSUs mean a power supply failure triggers an alert, not an outage - the second unit carries the load while the failed unit is replaced, during business hours, without service interruption. Two pairs of hardware bypass ports add another layer: if the appliance itself fails, traffic bypasses the security engine entirely, keeping the network up while the firewall is serviced.
100 Mbps of Pure Security Throughput
Throughput ratings on firewalls are not theoretical - enabling every security service simultaneously is the real test. At 100 Mbps with full threat prevention, IPS, antivirus, application identification, and web protection active, the appliance maintains line rate. 10 Gigabit Ethernet ports plus 2 Gigabit Ethernet and 2 Combo ports provide the interface density for multi-segment perimeter deployments without external switches.
Local Storage for Audit and Forensics
The 500 GB internal drive stores attack data, logs, and quarantined files locally - independent of cloud connectivity. When a security incident requires forensic analysis, the data is on the appliance, not in a remote data centre. Network situation awareness draws on this local storage to generate security grading and visual reports without depending on external systems.
Full Security Stack, Single Management Pane
Firewall, IPS, antivirus, web protection, DDoS mitigation, application identification, behaviour control, VPN, and authentication - twelve integrated functions managed from one configuration interface. The global policy view eliminates the configuration conflicts that arise when separate point solutions are managed independently. Application identification at action-level granularity integrates with intrusion detection and content filtering for coherent policy enforcement.
Networking That Adapts
IPv4/IPv6 dual-stack with OSPF, BGP, and RIPng. Intelligent service routing with bandwidth-ratio and link-health load balancing across multiple WAN connections. IPSec VPN and SSL VPN with SM2/SM3/SM4 national encryption for compliance. The appliance operates on 100-240V AC across 0-45°C at 2.9 kg - standard 1U rack-mount with no special cooling requirements.
Product Features
Dual Redundant Power Supplies
Two independent power supply units in N+1 configuration. One PSU can be removed and replaced while the appliance continues forwarding traffic at full throughput. Power redundancy protects against the most common hardware failure mode in deployed security appliances.
Hardware Bypass on Two Port Pairs
Two pairs of hardware bypass ports maintain network connectivity even if the appliance experiences a complete hardware or software failure. Traffic continues to flow through the bypass path, ensuring that the firewall never becomes a network-wide single point of failure.
100 Mbps Full-Service Throughput
10 Gigabit Ethernet ports plus 2 Gigabit Ethernet and 2 Combo ports provide multi-segment connectivity. At 100 Mbps with all security services active - IPS, antivirus, application identification, web protection - the appliance maintains line rate without degradation.
500 GB Local Storage for Audit and Forensics
Onboard storage retains attack data, security logs, and quarantined files independently of cloud connectivity. Network situation awareness draws on local data to generate security grading and visual reports. Forensic analysis does not depend on external storage systems.
Application Identification at Action Level
Over 10,000 applications identified with control precision down to individual actions. This granularity means blocking file transfers within an approved messaging application, rather than blocking the application entirely. Identification feeds directly into IPS and antivirus engines for correlated threat assessment.
Encrypted VPN with National and International Standards
IPSec VPN, SSL VPN, and GRE with SM2/SM3/SM4 national encryption standards plus 3DES, AES, and SHA. Single platform covers both domestic regulatory compliance and international interoperability for encrypted remote access.
Product Parameters
|
Parameter |
Specification |
|
Model |
NGFW-8108R |
|
Product Type |
Next-Generation Firewall (NGFW) |
|
Applicable Bandwidth |
100 Mbps |
|
Standard Interfaces |
10 x Gigabit Ethernet + 2 x Gigabit Ethernet + 2 x Combo |
|
Expansion Slots |
None |
|
Hardware Bypass |
2 Pairs |
|
Standard Hard Drive |
500 GB |
|
Dimensions |
1U Standard Chassis |
|
Weight |
2.9 kg |
|
Power Supply |
Dual Redundant, AC 100-240V |
|
Operating Temperature |
0 to 45°C |
|
Operating Humidity |
5% to 95% RH, Non-Condensing |
|
Routing Protocols |
Static, RIP, OSPF, BGP (IPv4); RIPng (IPv6) |
|
VPN Support |
IPSec VPN, SSL VPN, GRE |
|
Encryption |
3DES, AES, SHA, SM2, SM3, SM4 |
|
Application Identification |
10,000+ Applications |
|
Virus Detection |
4M+ Variants, Weekly Updates |
|
DDoS Protection |
ICMP, ICMPv6, UDP, SYN, ACK, DNS, HTTP, SIP, ARP |
|
Security Features |
Firewall, IPS, AV, Web Protection, DDoS, App-ID, VPN, Behaviour Control, Authentication, Load Balancing |
|
Management |
Web GUI, Local/Cloud, Multi-Dimensional Alarms, Visual Reports |
|
Warranty |
1 Year (Extendable) |
|
MOQ |
1 Unit |
|
OEM / ODM |
Supported |
Product Advantages
Redundant Power Means Redundant Uptime
Dual PSUs eliminate the single most common cause of appliance failure. When a power supply fails - and eventually one will - the second carries the load without interruption. Replacement happens during normal business hours, not during an emergency call-out.
01
Hardware Bypass Keeps the Network Alive
If the security engine fails, two pairs of bypass ports maintain data plane connectivity. The network stays up. The firewall gets serviced. These two events are independent - the bypass architecture ensures that.
02
Local Storage for When the Cloud Is Not Enough
500 GB onboard storage keeps logs, attack data, and quarantined files local. Forensics do not depend on internet connectivity or cloud availability. Compliance audits do not require data export to external systems before review.
03
100 Mbps Throughput with Every Feature Active
Throughput specifications that only apply with features disabled are misleading. This appliance delivers 100 Mbps with IPS, antivirus, application identification, and web protection simultaneously active - real throughput for real deployments.
04
One Policy Surface for Twelve Security Functions
Global configuration view eliminates the policy conflicts inherent in managing separate firewall, IPS, VPN, and content filtering devices. Integrated management reduces operator error and accelerates incident response.
05
Application Scenarios
Multi-Site Retail Branch Security
Deployed across retail locations where POS and inventory systems must stay online during business hours. Dual PSU and hardware bypass ensure that a power supply failure or appliance fault does not take the store offline. Cloud management provides centralised visibility across all locations.
Financial Branch Office Perimeter
100 Mbps throughput with full security inspection meets the performance requirements of mid-sized financial branches. SM2/SM3/SM4 encryption ensures regulatory compliance. Local storage retains transaction logs and security events for audit purposes without cloud dependency.
Campus Distribution Layer Security
10 Gigabit ports connect to distribution switches with multi-segment policy enforcement. Hardware bypass ensures that the campus network stays operational during firewall maintenance or failure. 500 GB local storage supports on-site security event correlation and reporting.
Certification
CE, FCC
